Sketch The Graph Of Each Function Algebra 1

Let's explore the fascinating world of graphing functions in Algebra 1. Graphing is a powerful tool that allows us to visualize relationships between variables and understand the behavior of functions. In this comprehensive guide, we'll cover the fundamentals of graphing, different types of functions you'll encounter in Algebra 1, and step-by-step instructions on how to sketch their graphs. Mastering these skills will not only help you succeed in your Algebra 1 course but also provide a solid foundation for more advanced mathematical concepts.

Understanding the Coordinate Plane

Before we dive into graphing functions, it's essential to understand the coordinate plane, also known as the Cartesian plane. This plane is formed by two perpendicular lines: the horizontal x-axis and the vertical y-axis. The point where these two axes intersect is called the origin, and it's represented by the coordinates (0, 0).

• x-axis: Represents the input values or independent variable.
• y-axis: Represents the output values or dependent variable.

Any point on the coordinate plane can be uniquely identified by an ordered pair (x, y), where x is the horizontal distance from the origin and y is the vertical distance from the origin.

Key Concepts for Graphing Functions

• Function: A relation between a set of inputs and a set of permissible outputs with the property that each input is related to exactly one output.
• Domain: The set of all possible input values (x-values) for which the function is defined.
• Range: The set of all possible output values (y-values) that the function can produce.
• Intercepts: Points where the graph intersects the x-axis (x-intercepts) or the y-axis (y-intercept).
• Slope: A measure of the steepness and direction of a line.
• Linear Function: A function whose graph is a straight line.
• Non-linear Function: A function whose graph is not a straight line (e.g., quadratic, exponential, absolute value).

Graphing Linear Functions

Linear functions are the simplest type of functions to graph. They have the general form:

y = mx + b

Where:

• m is the slope of the line
• b is the y-intercept (the point where the line crosses the y-axis)

Steps to Graph a Linear Function:

1. Identify the slope (m) and y-intercept (b).
2. Plot the y-intercept (0, b) on the coordinate plane.
3. Use the slope (m) to find another point on the line. Remember that the slope can be interpreted as "rise over run." For example, if the slope is 2/3, start at the y-intercept and move up 2 units (rise) and right 3 units (run) to find another point.
4. Draw a straight line through the two points. Extend the line in both directions to show that the function continues infinitely.
5. Label the line with the equation of the function.

Example 1: Graph y = 2x + 1

1. Slope (m): 2
2. y-intercept (b): 1
3. Plot the y-intercept (0, 1).
4. Use the slope (2/1) to find another point: Start at (0, 1), move up 2 units and right 1 unit to find the point (1, 3).
5. Draw a straight line through (0, 1) and (1, 3).
6. Label the line as y = 2x + 1.

Example 2: Graph y = -x + 3

1. Slope (m): -1
2. y-intercept (b): 3
3. Plot the y-intercept (0, 3).
4. Use the slope (-1/1) to find another point: Start at (0, 3), move down 1 unit and right 1 unit to find the point (1, 2).
5. Draw a straight line through (0, 3) and (1, 2).
6. Label the line as y = -x + 3.

Graphing Horizontal and Vertical Lines

Horizontal and vertical lines are special cases of linear functions.

• Horizontal Line: Has the equation y = c, where c is a constant. The slope is always 0. The line passes through all points with a y-coordinate of c.
• Vertical Line: Has the equation x = c, where c is a constant. The slope is undefined. The line passes through all points with an x-coordinate of c. Note: Vertical lines are NOT functions.

Example 3: Graph y = 4

This is a horizontal line passing through all points with a y-coordinate of 4. Draw a horizontal line through the point (0, 4).

Example 4: Graph x = -2

This is a vertical line passing through all points with an x-coordinate of -2. Draw a vertical line through the point (-2, 0).

Graphing Quadratic Functions

Quadratic functions have the general form:

y = ax^2 + bx + c

Where a, b, and c are constants, and a is not equal to 0. The graph of a quadratic function is a parabola, which is a U-shaped curve.

Key Features of a Parabola:

• Vertex: The highest or lowest point on the parabola. The vertex is the turning point of the parabola.
• Axis of Symmetry: A vertical line that passes through the vertex, dividing the parabola into two symmetrical halves.
• x-intercepts (Roots or Zeros): The points where the parabola intersects the x-axis. A parabola can have zero, one, or two x-intercepts.
• y-intercept: The point where the parabola intersects the y-axis.

Steps to Graph a Quadratic Function:

1. Find the vertex. The x-coordinate of the vertex can be found using the formula:

   x = -b / 2a


   Substitute this value of x into the quadratic equation to find the y-coordinate of the vertex.

2. Find the axis of symmetry. The axis of symmetry is a vertical line with the equation x = (x-coordinate of the vertex).

3. Find the y-intercept. Substitute x = 0 into the quadratic equation to find the y-intercept.

4. Find the x-intercepts (if any). Set y = 0 in the quadratic equation and solve for x. You can use factoring, the quadratic formula, or completing the square to find the x-intercepts. The quadratic formula is:

   x = (-b ± √(b^2 - 4ac)) / 2a


5. Plot the vertex, axis of symmetry, y-intercept, and x-intercepts (if any).

6. Sketch the parabola. Draw a smooth U-shaped curve through the plotted points, making sure the parabola is symmetrical about the axis of symmetry.

7. Label the parabola with the equation of the function.

Example 5: Graph y = x^2 - 4x + 3

1. Find the vertex:

   • x = -(-4) / (2 * 1) = 4 / 2 = 2
   • y = (2)^2 - 4(2) + 3 = 4 - 8 + 3 = -1
   • Vertex: (2, -1)

2. Find the axis of symmetry: x = 2

3. Find the y-intercept: y = (0)^2 - 4(0) + 3 = 3 y-intercept: (0, 3)

4. Find the x-intercepts:

   • 0 = x^2 - 4x + 3
   • 0 = (x - 1)(x - 3)
   • x = 1 or x = 3
   • x-intercepts: (1, 0) and (3, 0)

5. Plot the vertex (2, -1), axis of symmetry x = 2, y-intercept (0, 3), and x-intercepts (1, 0) and (3, 0).

6. Sketch the parabola.

7. Label the parabola as y = x^2 - 4x + 3.

Example 6: Graph y = -x^2 + 2x + 1

1. Find the vertex:

   • x = -2 / (2 * -1) = -2 / -2 = 1
   • y = -(1)^2 + 2(1) + 1 = -1 + 2 + 1 = 2
   • Vertex: (1, 2)

2. Find the axis of symmetry: x = 1

3. Find the y-intercept: y = -(0)^2 + 2(0) + 1 = 1 y-intercept: (0, 1)

4. Find the x-intercepts:

   • 0 = -x^2 + 2x + 1
   • Using the quadratic formula: x = (-2 ± √(2^2 - 4(-1)(1))) / (2 * -1)
   • x = (-2 ± √(8)) / -2 = (-2 ± 2√2) / -2 = 1 ± √2
   • x-intercepts: (1 + √2, 0) ≈ (2.41, 0) and (1 - √2, 0) ≈ (-0.41, 0)

5. Plot the vertex (1, 2), axis of symmetry x = 1, y-intercept (0, 1), and x-intercepts (approximately) (2.41, 0) and (-0.41, 0).

6. Sketch the parabola. Note that because the coefficient of x^2 is negative, the parabola opens downwards.

7. Label the parabola as y = -x^2 + 2x + 1.

Graphing Absolute Value Functions

Absolute value functions have the general form:

y = a|x - h| + k

Where a, h, and k are constants. The graph of an absolute value function is a V-shaped graph.

Key Features of an Absolute Value Function:

• Vertex: The point where the V-shape changes direction. The vertex is at the point (h, k).
• Axis of Symmetry: A vertical line that passes through the vertex.
• Slope: The slope of the lines on either side of the vertex.

Steps to Graph an Absolute Value Function:

1. Find the vertex. The vertex is at the point (h, k). Remember that in the equation y = a|x - h| + k, the value of h is subtracted from x, so be careful with the sign.
2. Find the axis of symmetry. The axis of symmetry is a vertical line with the equation x = h.
3. Find a few points on either side of the vertex. Choose x-values that are greater than and less than the x-coordinate of the vertex. Substitute these x-values into the absolute value equation to find the corresponding y-values.
4. Plot the vertex and the points you found in step 3.
5. Sketch the V-shaped graph. Draw two lines extending from the vertex, passing through the plotted points.
6. Label the graph with the equation of the function.

Example 7: Graph y = |x - 2| + 1

1. Find the vertex:

   • The equation is in the form y = a|x - h| + k, where a = 1, h = 2, and k = 1.
   • Vertex: (2, 1)

2. Find the axis of symmetry: x = 2

3. Find a few points on either side of the vertex:

   • Let x = 0: y = |0 - 2| + 1 = |-2| + 1 = 2 + 1 = 3 Point: (0, 3)
   • Let x = 1: y = |1 - 2| + 1 = |-1| + 1 = 1 + 1 = 2 Point: (1, 2)
   • Let x = 3: y = |3 - 2| + 1 = |1| + 1 = 1 + 1 = 2 Point: (3, 2)
   • Let x = 4: y = |4 - 2| + 1 = |2| + 1 = 2 + 1 = 3 Point: (4, 3)

4. Plot the vertex (2, 1) and the points (0, 3), (1, 2), (3, 2), and (4, 3).

5. Sketch the V-shaped graph.

6. Label the graph as y = |x - 2| + 1.

Example 8: Graph y = -2|x + 1| - 3

1. Find the vertex:

   • The equation is in the form y = a|x - h| + k, where a = -2, h = -1, and k = -3. Remember that x + 1 is the same as x - (-1).
   • Vertex: (-1, -3)

2. Find the axis of symmetry: x = -1

3. Find a few points on either side of the vertex:

   • Let x = -3: y = -2|-3 + 1| - 3 = -2|-2| - 3 = -2(2) - 3 = -4 - 3 = -7 Point: (-3, -7)
   • Let x = -2: y = -2|-2 + 1| - 3 = -2|-1| - 3 = -2(1) - 3 = -2 - 3 = -5 Point: (-2, -5)
   • Let x = 0: y = -2|0 + 1| - 3 = -2|1| - 3 = -2(1) - 3 = -2 - 3 = -5 Point: (0, -5)
   • Let x = 1: y = -2|1 + 1| - 3 = -2|2| - 3 = -2(2) - 3 = -4 - 3 = -7 Point: (1, -7)

4. Plot the vertex (-1, -3) and the points (-3, -7), (-2, -5), (0, -5), and (1, -7).

5. Sketch the V-shaped graph. Notice that because a is negative, the V-shape opens downwards.

6. Label the graph as y = -2|x + 1| - 3.

Graphing Piecewise Functions

A piecewise function is a function defined by multiple sub-functions, each applying to a certain interval of the domain.

Steps to Graph a Piecewise Function:

1. Identify the intervals and their corresponding sub-functions.
2. Graph each sub-function over its specified interval. Pay close attention to the endpoints of the intervals. Use open circles (o) for points that are not included in the interval and closed circles (•) for points that are included.
3. Combine the graphs of the sub-functions to create the graph of the piecewise function.

Example 9: Graph the piecewise function:

f(x) =  { x + 2,  if x < 1
          { 3,      if 1 ≤ x ≤ 4
          { -x + 7, if x > 4

1. Identify the intervals and sub-functions:

   • For x < 1: f(x) = x + 2 (a linear function)
   • For 1 ≤ x ≤ 4: f(x) = 3 (a horizontal line)
   • For x > 4: f(x) = -x + 7 (a linear function)

2. Graph each sub-function over its interval:

   • For x < 1: f(x) = x + 2: This is a line with a slope of 1 and a y-intercept of 2. However, it only applies for x < 1. At x = 1, the value would be 1 + 2 = 3. So, draw a line with slope 1 and y-intercept 2, but stop at x = 1 and put an open circle at the point (1, 3) to indicate that this point is not included.
   • For 1 ≤ x ≤ 4: f(x) = 3: This is a horizontal line at y = 3. It only applies between x = 1 and x = 4, inclusive. So, draw a horizontal line segment from x = 1 to x = 4, with closed circles at both endpoints (1, 3) and (4, 3) to indicate that these points are included.
   • For x > 4: f(x) = -x + 7: This is a line with a slope of -1 and a y-intercept of 7. However, it only applies for x > 4. At x = 4, the value would be -4 + 7 = 3. So, draw a line with slope -1 and y-intercept 7, starting at x = 4 and put an open circle at the point (4, 3) to indicate that this point is not included.

3. Combine the graphs: The graph of the piecewise function consists of the three pieces described above. Notice how the open and closed circles are important for showing where the function is defined.

Tips for Success in Graphing Functions

• Practice Regularly: The more you practice graphing functions, the better you'll become at it.
• Use Graphing Paper: Graphing paper can help you draw accurate graphs.
• Use a Ruler: A ruler will help you draw straight lines.
• Double-Check Your Work: Make sure you've plotted the points correctly and drawn the graph accurately.
• Use Graphing Software or Calculators: Tools like Desmos or a graphing calculator can help you visualize functions and check your work. However, it's important to understand the underlying concepts and be able to graph functions by hand.
• Pay Attention to Details: Be careful with signs, slopes, intercepts, and endpoints.
• Understand the Transformations of Functions: Knowing how to shift, stretch, and reflect functions can make graphing easier.
• Relate the Equation to the Graph: Try to understand how the equation of a function determines the shape and position of its graph.

Common Mistakes to Avoid

• Incorrectly Plotting Points: Make sure you're plotting the x and y coordinates in the correct order.
• Drawing Lines That Aren't Straight: Use a ruler to draw straight lines for linear functions.
• Not Labeling the Graph: Always label the graph with the equation of the function.
• Ignoring the Domain and Range: Consider the domain and range of the function when sketching the graph.
• Confusing Slope and Intercept: Make sure you understand the difference between the slope and the y-intercept.
• Forgetting Open and Closed Circles: When graphing piecewise functions, remember to use open circles for points that are not included in the interval and closed circles for points that are included.

Conclusion

Graphing functions is a fundamental skill in Algebra 1. By understanding the coordinate plane, the different types of functions, and the steps involved in graphing, you can master this skill and use it to solve a variety of problems. Remember to practice regularly, pay attention to details, and use available tools to help you visualize functions and check your work. With dedication and effort, you'll be well on your way to becoming a graphing pro!
