Examples Of Shear And Moment Diagrams

Shear and moment diagrams are essential tools in structural engineering, used to analyze the internal forces and moments within a beam subjected to external loads. These diagrams visually represent the shear force and bending moment at every point along the beam, enabling engineers to determine the beam's strength, stability, and deflection. This comprehensive article will delve into various examples of shear and moment diagrams, illustrating how to construct and interpret them for different loading conditions and beam configurations.

Understanding Shear and Moment Diagrams

Before diving into examples, let's establish a firm understanding of the fundamental concepts:

• Shear Force (V): The internal force acting perpendicular to the beam's axis at a given point. It represents the tendency of one part of the beam to slide vertically relative to the adjacent part.
• Bending Moment (M): The internal moment acting about the beam's axis at a given point. It represents the tendency of the beam to bend or rotate due to external loads.

Shear and moment diagrams plot these values (V and M) along the length of the beam (x). Conventionally, shear force is considered positive if it causes a clockwise rotation to the left of the section and negative if it causes a counter-clockwise rotation. Bending moment is considered positive if it causes compression in the top fibers of the beam (sagging) and negative if it causes tension in the top fibers (hogging).

Basic Principles for Constructing Shear and Moment Diagrams

The construction of shear and moment diagrams relies on a few key principles:

• Equilibrium: The sum of vertical forces and moments must be zero at any section of the beam.
• Relationship between Load, Shear, and Moment:
  • The slope of the shear diagram at any point is equal to the negative of the distributed load at that point: dV/dx = -w(x)
  • The slope of the moment diagram at any point is equal to the shear force at that point: dM/dx = V(x)
  • The area under the shear diagram between two points represents the change in bending moment between those points.
• Concentrated Loads: Cause a vertical jump in the shear diagram.
• Concentrated Moments: Cause a vertical jump in the moment diagram.
• Supports:
  • Pin or Hinge: Allows rotation, so the moment is zero at the support. It provides both vertical and horizontal reactions.
  • Roller: Allows rotation and horizontal movement, so the moment is zero at the support. It provides only a vertical reaction.
  • Fixed: Prevents rotation and movement, so both moment and shear can exist at the support.

Example 1: Simply Supported Beam with a Concentrated Load at Midspan

Consider a simply supported beam of length L subjected to a concentrated load P at its midspan (L/2).

1. Reactions:

Due to symmetry, the vertical reactions at both supports (A and B) are equal: RA = RB = P/2

2. Shear Diagram:

• From A to L/2: The shear force is constant and equal to the reaction at A: V = P/2 (positive).
• At L/2: The shear force jumps down by the magnitude of the concentrated load P: V = P/2 - P = -P/2.
• From L/2 to B: The shear force remains constant at V = -P/2 (negative).

3. Moment Diagram:

• From A to L/2: The bending moment increases linearly from zero at A to a maximum value at L/2. The moment at L/2 is the area under the shear diagram: M = (P/2) * (L/2) = PL/4.
• From L/2 to B: The bending moment decreases linearly from PL/4 at L/2 to zero at B.

Key Observations:

• The shear diagram is a rectangle with a jump at the point of application of the concentrated load.
• The moment diagram is a triangle, with the maximum moment occurring at the midspan where the concentrated load is applied.

Example 2: Simply Supported Beam with a Uniformly Distributed Load (UDL)

Consider a simply supported beam of length L subjected to a uniformly distributed load (UDL) of intensity w (force per unit length) over the entire span.

1. Reactions:

Due to symmetry, the vertical reactions at both supports are equal: RA = RB = wL/2

2. Shear Diagram:

• At A: The shear force is equal to the reaction at A: V = wL/2 (positive).
• Along the beam: The shear force decreases linearly with distance x from A: V(x) = wL/2 - wx.
• At L/2: The shear force is zero: V(L/2) = wL/2 - w(L/2) = 0.
• At B: The shear force is equal to the negative of the reaction at B: V = -wL/2 (negative).

3. Moment Diagram:

• The bending moment is zero at the supports (A and B).
• The bending moment increases from A to L/2 and then decreases from L/2 to B.
• The bending moment at any point x from A is the integral of the shear force: M(x) = ∫V(x) dx = ∫(wL/2 - wx) dx = (wL/2)x - (wx^2)/2 + C. Since M(0) = 0, C = 0. Therefore, M(x) = (wL/2)x - (wx^2)/2.
• The maximum bending moment occurs at L/2: M(L/2) = (wL/2)(L/2) - (w(L/2)^2)/2 = wL^2/8.

Key Observations:

• The shear diagram is a sloping line, decreasing linearly from one support to the other.
• The moment diagram is a parabola, with the maximum moment occurring at the midspan.

Example 3: Cantilever Beam with a Concentrated Load at the Free End

Consider a cantilever beam of length L with a concentrated load P applied at the free end.

1. Reactions:

• At the fixed end (A), there is a vertical reaction RA = P (upwards) and a moment reaction MA = PL (counter-clockwise).

2. Shear Diagram:

• From the free end to the fixed end: The shear force is constant and equal to the negative of the applied load: V = -P.

3. Moment Diagram:

• At the free end: The bending moment is zero.
• The bending moment increases linearly from zero at the free end to M = -PL at the fixed end (A). The moment is negative because it causes tension in the top fibers (hogging).

Key Observations:

• The shear diagram is a rectangle with a constant value of -P.
• The moment diagram is a triangle, with the maximum moment at the fixed end.

Example 4: Cantilever Beam with a Uniformly Distributed Load (UDL)

Consider a cantilever beam of length L subjected to a uniformly distributed load (UDL) of intensity w over the entire span.

1. Reactions:

• At the fixed end (A), there is a vertical reaction RA = wL (upwards) and a moment reaction MA = (wL^2)/2 (counter-clockwise).

2. Shear Diagram:

• At the free end: The shear force is zero.
• The shear force increases linearly from zero at the free end to V = -wL at the fixed end (A). The shear force is negative.

3. Moment Diagram:

• At the free end: The bending moment is zero.
• The bending moment increases quadratically from zero at the free end to M = -(wL^2)/2 at the fixed end (A). The moment is negative because it causes tension in the top fibers (hogging). The moment at a distance x from the free end is M(x) = -w(x^2)/2.

Key Observations:

• The shear diagram is a sloping line, increasing linearly from the free end to the fixed end.
• The moment diagram is a parabola, with the maximum moment at the fixed end.

Example 5: Overhanging Beam with a Concentrated Load

Consider an overhanging beam supported at points A and B, with a length L between the supports and an overhang of length a beyond support B. A concentrated load P is applied at the free end of the overhang.

1. Reactions:

• Sum of moments about A: RB * L - P * (L+a) = 0 => RB = P(L+a)/L
• Sum of vertical forces: RA + RB - P = 0 => RA = P - RB = P - P(L+a)/L = -Pa/L (downward)

2. Shear Diagram:

• From the free end of the overhang to B: The shear force is constant and equal to -P.
• At B: The shear force jumps up by the magnitude of the reaction at B: V = -P + P(L+a)/L = Pa/L.
• From A to B: The shear force is constant and equal to Pa/L.
• At A: The shear force jumps down by the magnitude of the reaction at A: V = Pa/L - Pa/L = 0.

3. Moment Diagram:

• From the free end of the overhang to B: The bending moment increases linearly from zero at the free end to M = -Pa at B. The moment is negative.
• From A to B: The bending moment decreases linearly from M = 0 at A to M = -Pa at B.

Key Observations:

• The shear diagram has a jump at the concentrated load and at support B.
• The moment diagram is linear in both sections, with a negative moment over the support B.

Example 6: Beam with a Combination of Loads

Consider a simply supported beam of length L with a concentrated load P at L/3 and a UDL of w over the entire span.

1. Reactions:

• Sum of moments about A: RB * L - P * (L/3) - (wL) * (L/2) = 0 => RB = P/3 + wL/2
• Sum of vertical forces: RA + RB - P - wL = 0 => RA = P + wL - RB = P + wL - (P/3 + wL/2) = (2P/3) + (wL/2)

2. Shear Diagram:

• From A to L/3: The shear force decreases linearly from RA = (2P/3) + (wL/2) to (2P/3) + (wL/2) - w(L/3) = (2P/3) + (wL/6).
• At L/3: The shear force jumps down by the magnitude of the concentrated load P: (2P/3) + (wL/6) - P = -(P/3) + (wL/6).
• From L/3 to B: The shear force decreases linearly from -(P/3) + (wL/6) to -(P/3) + (wL/6) - w(2L/3) = -(P/3) - (wL/2) = -RB.

3. Moment Diagram:

• The moment diagram will be parabolic between A and L/3 and then another parabola between L/3 and B, reflecting the UDL.
• The bending moment at L/3 will have a local maximum. The exact shape and values require integration and solving for the point of zero shear (maximum moment).

Key Observations:

• This example demonstrates how to combine the effects of concentrated loads and UDLs.
• The shear and moment diagrams become more complex, requiring careful calculation.

Tips for Drawing Accurate Shear and Moment Diagrams

• Start with the reactions: Accurately calculate the support reactions before drawing the diagrams.
• Follow the sign conventions: Consistently apply the sign conventions for shear force and bending moment.
• Draw neatly: Use a ruler and graph paper to create clear and accurate diagrams.
• Check for equilibrium: Verify that the diagrams are consistent with the equilibrium equations.
• Identify key points: Determine the locations of maximum and minimum shear force and bending moment.
• Understand the relationships: Remember the relationships between load, shear, and moment.
• Practice: The more you practice, the better you will become at constructing and interpreting shear and moment diagrams.

Applications of Shear and Moment Diagrams

Shear and moment diagrams are used for a wide range of structural engineering applications, including:

• Determining the maximum shear force and bending moment: This information is essential for selecting the appropriate size and material for a beam.
• Checking the adequacy of a beam: Engineers can use shear and moment diagrams to verify that a beam can safely support the applied loads.
• Calculating the deflection of a beam: The bending moment diagram can be used to calculate the deflection of a beam using methods such as the moment-area method or the conjugate beam method.
• Designing reinforced concrete beams: Shear and moment diagrams are used to determine the amount of reinforcement required in a concrete beam.
• Analyzing complex structures: Shear and moment diagrams can be used as a tool to analyze more complex structures, such as frames and trusses.

Conclusion

Shear and moment diagrams are powerful tools for understanding the behavior of beams under load. By mastering the principles and techniques for constructing and interpreting these diagrams, engineers can design safe, efficient, and reliable structures. The examples provided in this article offer a solid foundation for further exploration and application of these essential concepts in structural analysis and design. Continuous practice and a thorough understanding of the underlying principles are key to becoming proficient in using shear and moment diagrams effectively. Remember to always double-check your work and consider the limitations of the assumptions made in the analysis. Good luck!
