Algebra 2: Sketching the Graph of Each Function

Sketching graphs is a fundamental skill in Algebra 2, allowing you to visualize the behavior and properties of various functions. This process involves understanding the function's equation, identifying key features, and plotting points to create an accurate representation. Let’s delve into different types of functions and how to sketch their graphs.

1. Linear Functions

Linear functions are the simplest and most fundamental type of function.

• General Form: f(x) = mx + b, where m is the slope and b is the y-intercept.

  • The slope (m) indicates the steepness and direction of the line. A positive slope means the line goes upward from left to right, while a negative slope means it goes downward.
  • The y-intercept (b) is the point where the line crosses the y-axis, i.e., the value of f(x) when x = 0.

• How to Sketch:

  1. Identify the y-intercept (b): Plot this point on the y-axis.
  2. Use the slope (m) to find another point: Remember that slope is rise over run. From the y-intercept, move up (or down, if the slope is negative) by the "rise" and move right by the "run." Plot this second point.
  3. Draw a straight line: Connect the two points to create the line representing the function.

• Example: f(x) = 2x + 3

  1. The y-intercept is 3, so plot the point (0, 3).
  2. The slope is 2, which can be written as 2/1. From (0, 3), move up 2 units and right 1 unit to find the point (1, 5).
  3. Draw a line through (0, 3) and (1, 5).

2. Quadratic Functions

Quadratic functions form parabolas, U-shaped curves that open upward or downward.

• General Form: f(x) = ax² + bx + c, where a, b, and c are constants.

• Key Features:

  • Vertex: The turning point of the parabola, which can be a maximum or minimum.
  • Axis of Symmetry: A vertical line that passes through the vertex, dividing the parabola into two symmetrical halves. The equation is x = -b / 2a.
  • x-intercepts (Roots/Zeros): The points where the parabola crosses the x-axis, found by setting f(x) = 0 and solving for x.
  • y-intercept: The point where the parabola crosses the y-axis, found by setting x = 0 in the equation.

• How to Sketch:

  1. Find the vertex: Use the formula x = -b / 2a to find the x-coordinate of the vertex. Then, substitute this value into the function to find the y-coordinate.
  2. Determine the axis of symmetry: This is the vertical line x = -b / 2a.
  3. Find the y-intercept: Set x = 0 to find the y-intercept. Plot this point.
  4. Find the x-intercepts (if they exist): Set f(x) = 0 and solve for x. You can use factoring, completing the square, or the quadratic formula. Plot these points.
  5. Determine the direction of opening: If a > 0, the parabola opens upward. If a < 0, it opens downward.
  6. Plot additional points: Choose a few x-values on either side of the vertex and calculate the corresponding y-values.
  7. Sketch the parabola: Draw a smooth curve through the points, ensuring it is symmetrical about the axis of symmetry.

• Example: f(x) = x² - 4x + 3

  1. Vertex: x = -(-4) / (2 * 1) = 2. f(2) = 2² - 4(2) + 3 = -1. So, the vertex is (2, -1).
  2. Axis of Symmetry: x = 2.
  3. y-intercept: f(0) = 0² - 4(0) + 3 = 3. The y-intercept is (0, 3).
  4. x-intercepts: Set x² - 4x + 3 = 0. Factoring gives (x - 1)(x - 3) = 0. The x-intercepts are x = 1 and x = 3, so the points are (1, 0) and (3, 0).
  5. Direction of Opening: Since a = 1 > 0, the parabola opens upward.
  6. Plot and Sketch: Plot the vertex, intercepts, and a few additional points. Draw a smooth upward-opening parabola.

3. Cubic Functions

Cubic functions are polynomials of degree 3 and can have various shapes, including one or two turning points.

• General Form: f(x) = ax³ + bx² + cx + d, where a, b, c, and d are constants.

• Key Features:

  • End Behavior: As x approaches positive or negative infinity, the function either increases or decreases without bound. If a > 0, as x → ∞, f(x) → ∞, and as x → -∞, f(x) → -∞. If a < 0, the behavior is reversed.
  • x-intercepts (Roots/Zeros): The points where the curve crosses the x-axis, found by setting f(x) = 0 and solving for x.
  • y-intercept: The point where the curve crosses the y-axis, found by setting x = 0 in the equation.
  • Turning Points (Local Maxima/Minima): Points where the function changes direction.

• How to Sketch:

  1. Determine the end behavior: Look at the sign of a to determine how the function behaves as x goes to positive and negative infinity.
  2. Find the y-intercept: Set x = 0 to find the y-intercept.
  3. Find the x-intercepts: Set f(x) = 0 and solve for x. This may involve factoring, synthetic division, or numerical methods.
  4. Find turning points (optional, requires calculus): If you know calculus, find the first derivative of the function and set it equal to zero to find critical points. These points are potential maxima or minima.
  5. Plot additional points: Choose several x-values, including those between the x-intercepts and turning points, to get a better sense of the curve.
  6. Sketch the curve: Draw a smooth curve through the points, ensuring it follows the end behavior and has the appropriate number of turning points.

• Example: f(x) = x³ - 3x² + 2x

  1. End Behavior: Since a = 1 > 0, as x → ∞, f(x) → ∞, and as x → -∞, f(x) → -∞.
  2. y-intercept: f(0) = 0³ - 3(0)² + 2(0) = 0. The y-intercept is (0, 0).
  3. x-intercepts: Set x³ - 3x² + 2x = 0. Factoring gives x(x² - 3x + 2) = x(x - 1)(x - 2) = 0. The x-intercepts are x = 0, 1, 2, so the points are (0, 0), (1, 0), and (2, 0).
  4. Plot additional points: Choose x = 0.5 and x = 1.5. f(0.5) = (0.5)³ - 3(0.5)² + 2(0.5) = 0.375, and f(1.5) = (1.5)³ - 3(1.5)² + 2(1.5) = -0.375. So, we have the points (0.5, 0.375) and (1.5, -0.375).
  5. Sketch the curve: Draw a smooth curve through the points, starting from the bottom left, going through (0, 0), rising to a maximum near (0.5, 0.375), falling through (1, 0), reaching a minimum near (1.5, -0.375), and rising through (2, 0) to the top right.

4. Absolute Value Functions

Absolute value functions create V-shaped graphs.

• General Form: f(x) = a|x - h| + k, where a determines the stretch and direction, (h, k) is the vertex, and |x| is the absolute value of x.

• Key Features:

  • Vertex: The point where the graph changes direction, which is (h, k).
  • Symmetry: The graph is symmetrical about the vertical line x = h.
  • Direction of Opening: If a > 0, the graph opens upward. If a < 0, the graph opens downward.

• How to Sketch:

  1. Identify the vertex: The vertex is (h, k). Plot this point.
  2. Determine the direction of opening: Look at the sign of a.
  3. Find additional points: Choose a few x-values on either side of the vertex and calculate the corresponding y-values.
  4. Sketch the graph: Draw two straight lines extending from the vertex, forming a V-shape.

• Example: f(x) = 2|x - 1| + 3

  1. Vertex: The vertex is (1, 3).
  2. Direction of Opening: Since a = 2 > 0, the graph opens upward.
  3. Additional Points:
     • x = 0: f(0) = 2|0 - 1| + 3 = 2(1) + 3 = 5. The point is (0, 5).
     • x = 2: f(2) = 2|2 - 1| + 3 = 2(1) + 3 = 5. The point is (2, 5).
  4. Sketch the graph: Plot the vertex (1, 3) and the points (0, 5) and (2, 5). Draw two lines extending from (1, 3) through these points, forming an upward-opening V-shape.

5. Square Root Functions

Square root functions start at a point and extend in one direction.

• General Form: f(x) = a√(x - h) + k, where a determines the stretch and direction, (h, k) is the starting point, and √x is the square root of x.

• Key Features:

  • Starting Point: The point where the graph begins, which is (h, k).
  • Direction: The graph extends to the right if the coefficient of x inside the square root is positive, and to the left if it is negative.
  • Domain: x ≥ h if the coefficient of x is positive, and x ≤ h if it is negative.

• How to Sketch:

  1. Identify the starting point: The starting point is (h, k). Plot this point.
  2. Determine the direction of extension: Look at the sign of the coefficient of x inside the square root.
  3. Find additional points: Choose a few x-values greater than h (or less than h, if it extends to the left) and calculate the corresponding y-values.
  4. Sketch the graph: Draw a curve starting at the starting point and extending in the appropriate direction.

• Example: f(x) = √(x - 2) + 1

  1. Starting Point: The starting point is (2, 1).
  2. Direction of Extension: The graph extends to the right since the coefficient of x is positive.
  3. Additional Points:
     • x = 3: f(3) = √(3 - 2) + 1 = √1 + 1 = 2. The point is (3, 2).
     • x = 6: f(6) = √(6 - 2) + 1 = √4 + 1 = 3. The point is (6, 3).
  4. Sketch the graph: Plot the starting point (2, 1) and the points (3, 2) and (6, 3). Draw a curve starting at (2, 1) and extending to the right.

6. Rational Functions

Rational functions are ratios of two polynomials and can have asymptotes.

• General Form: f(x) = P(x) / Q(x), where P(x) and Q(x) are polynomials.

• Key Features:

  • Vertical Asymptotes: Occur at values of x where the denominator Q(x) = 0 and the numerator P(x) ≠ 0.
  • Horizontal Asymptotes: Determined by comparing the degrees of P(x) and Q(x).
    • If the degree of P(x) is less than the degree of Q(x), the horizontal asymptote is y = 0.
    • If the degree of P(x) is equal to the degree of Q(x), the horizontal asymptote is y = (leading coefficient of P(x)) / (leading coefficient of Q(x)).
    • If the degree of P(x) is greater than the degree of Q(x), there is no horizontal asymptote (but there may be a slant asymptote).
  • x-intercepts: Occur at values of x where the numerator P(x) = 0.
  • y-intercept: The point where the curve crosses the y-axis, found by setting x = 0 in the equation.

• How to Sketch:

  1. Find vertical asymptotes: Set the denominator equal to zero and solve for x.
  2. Find horizontal asymptote: Compare the degrees of the numerator and denominator.
  3. Find x-intercepts: Set the numerator equal to zero and solve for x.
  4. Find y-intercept: Set x = 0 to find the y-intercept.
  5. Plot asymptotes and intercepts: Draw dashed lines for the asymptotes.
  6. Choose test points: Pick x-values in each interval created by the vertical asymptotes and x-intercepts. Calculate the corresponding y-values to determine the behavior of the graph in each interval.
  7. Sketch the curve: Draw smooth curves through the points, approaching the asymptotes but never crossing them.

• Example: f(x) = (x + 1) / (x - 2)

  1. Vertical Asymptote: x - 2 = 0 => x = 2.
  2. Horizontal Asymptote: The degrees of the numerator and denominator are equal (both 1). The horizontal asymptote is y = 1/1 = 1.
  3. x-intercept: x + 1 = 0 => x = -1. The x-intercept is (-1, 0).
  4. y-intercept: f(0) = (0 + 1) / (0 - 2) = -1/2. The y-intercept is (0, -1/2).
  5. Test Points:
     • x < -1: Let x = -2. f(-2) = (-2 + 1) / (-2 - 2) = -1 / -4 = 1/4. The point is (-2, 1/4).
     • -1 < x < 2: Let x = 0. f(0) = -1/2 (already found).
     • x > 2: Let x = 3. f(3) = (3 + 1) / (3 - 2) = 4 / 1 = 4. The point is (3, 4).
  6. Sketch the curve: Draw the vertical asymptote at x = 2 and the horizontal asymptote at y = 1. Plot the intercepts and test points. Sketch smooth curves approaching the asymptotes.

7. Exponential Functions

Exponential functions show rapid growth or decay.

• General Form: f(x) = a⋅b^(x - h) + k, where a is the initial value, b is the base, (h, k) represents translations, and x is the exponent.

• Key Features:

  • Horizontal Asymptote: The line y = k. The graph approaches this line as x goes to positive or negative infinity.
  • y-intercept: The point where the curve crosses the y-axis, found by setting x = 0 in the equation.
  • Growth/Decay: If b > 1, the function represents exponential growth. If 0 < b < 1, the function represents exponential decay.

• How to Sketch:

  1. Identify the horizontal asymptote: This is the line y = k.
  2. Find the y-intercept: Set x = 0 to find the y-intercept.
  3. Find additional points: Choose a few x-values and calculate the corresponding y-values.
  4. Determine growth or decay: Look at the value of b.
  5. Sketch the graph: Draw a curve approaching the horizontal asymptote and passing through the points.

• Example: f(x) = 2^(x - 1) + 3

  1. Horizontal Asymptote: y = 3.
  2. y-intercept: f(0) = 2^(0 - 1) + 3 = 2^(-1) + 3 = 1/2 + 3 = 3.5. The y-intercept is (0, 3.5).
  3. Additional Points:
     • x = 1: f(1) = 2^(1 - 1) + 3 = 2^0 + 3 = 1 + 3 = 4. The point is (1, 4).
     • x = 2: f(2) = 2^(2 - 1) + 3 = 2^1 + 3 = 2 + 3 = 5. The point is (2, 5).
  4. Growth/Decay: Since b = 2 > 1, this is exponential growth.
  5. Sketch the graph: Draw the horizontal asymptote at y = 3. Plot the points (0, 3.5), (1, 4), and (2, 5). Draw a curve approaching the asymptote as x goes to negative infinity and increasing rapidly as x goes to positive infinity.

8. Logarithmic Functions

Logarithmic functions are inverses of exponential functions.

• General Form: f(x) = a⋅log_b(x - h) + k, where a is a stretch factor, b is the base, (h, k) represents translations, and log_b(x) is the logarithm of x to the base b.

• Key Features:

  • Vertical Asymptote: The line x = h. The graph approaches this line as x approaches h.
  • x-intercept: The point where the curve crosses the x-axis, found by setting f(x) = 0 and solving for x.
  • Domain: x > h.

• How to Sketch:

  1. Identify the vertical asymptote: This is the line x = h.
  2. Find the x-intercept: Set f(x) = 0 and solve for x.
  3. Find additional points: Choose a few x-values greater than h and calculate the corresponding y-values.
  4. Sketch the graph: Draw a curve approaching the vertical asymptote and passing through the points.

• Example: f(x) = log₂(x - 1) + 2

  1. Vertical Asymptote: x = 1.
  2. x-intercept: Set log₂(x - 1) + 2 = 0. log₂(x - 1) = -2. x - 1 = 2^(-2) = 1/4. x = 1 + 1/4 = 5/4. The x-intercept is (5/4, 0).
  3. Additional Points:
     • x = 2: f(2) = log₂(2 - 1) + 2 = log₂(1) + 2 = 0 + 2 = 2. The point is (2, 2).
     • x = 3: f(3) = log₂(3 - 1) + 2 = log₂(2) + 2 = 1 + 2 = 3. The point is (3, 3).
  4. Sketch the graph: Draw the vertical asymptote at x = 1. Plot the points (5/4, 0), (2, 2), and (3, 3). Draw a curve approaching the asymptote as x approaches 1 and increasing slowly as x increases.

Tips for Accurate Sketching

• Use graph paper: Helps in plotting points accurately.
• Label axes: Always label the x and y axes with appropriate scales.
• Identify key features: Before sketching, identify and mark the key features of the function, such as intercepts, asymptotes, and vertices.
• Plot enough points: Plotting more points provides a better understanding of the function's behavior.
• Practice: The more you practice, the better you become at recognizing patterns and sketching graphs quickly and accurately.

By understanding the general forms, key features, and sketching techniques for various functions, you can accurately represent them graphically in Algebra 2. Practice is key to mastering this essential skill.
